Home >> High end Concrete pump hose
  • High end Concrete pump hose

  • High end Concrete pump hose

    Name：High end Concrete pump Rubber Hose

    Feature: High wear-resistance, outstanding performance.

    Specification：5‘’ Dn125mm

    Material：Natrual rubber

    Reinforcement： 4layer steel wire

    Wall thickness：8.0mm

    Length：1meter -12meter

    Flange：148mm/157mm/166mm

    Working Pressure：85bar

    Burst Pressure:300bar.

    Application：Concrete/ cement delivery

    Can Apply to：Concrete pump boom truck,trailer pump,stationary pump,portable pump,placing boom,Drilling...etc Concrete pumping machineries in construction site.


    • 0.00
      0.00
Product Description

Name：High end Concrete pump Rubber Hose

Feature: High wear-resistance, outstanding performance.

Specification：5‘’ Dn125mm

Material：Natrual rubber

Reinforcement： 4layer steel wire

Wall thickness：8.0mm

Length：1meter -12meter

Flange：148mm/157mm/166mm

Working Pressure：85bar

Burst Pressure:300bar.

Application：Concrete/ cement delivery

Can Apply to：Concrete pump boom truck,trailer pump,stationary pump,portable pump,placing boom,Drilling...etc Concrete pumping machineries in construction site.


High-pressure hardened hose fitting(end) 16Mn ,after quenching treatment ,ensures much more wear-resisting.

Inner layer apply natural rubber with technical accelerants and anti-aging agents,enhanced rubber hose tolerance

Reinforcement apply 4layer steel wires enhanced the pressure-resistant and explosion-proof performance of the rubber hose.

Anti-aging external rubber layer ensures hose resisting blows,stretching and ageing.、
